Listings Page

Click in the boxes below, select all and copy to grab the applet

HTML listing:

</APPLET>
</BODY>
</HTML>

Applet listing:

/*
	Copyright: Sun Microsystems 1997.  All rights reserved.
	Author: Patrick Chan (www.xeo.com)   7/19/96
	Version: 1.1
*/

import java.applet.*;
import java.awt.*;
import java.util.*;
import java.net.*;

public class XeoMenu extends Applet {
	// The background image.  This had better not be null.
	Image image;

// These two fields are used to do double-buffering.
	// The dimensions of bbuf is exactly the dimensions of the applet.
	Image bbuf;
	Graphics bbufG;

// This field is set to true only when the background image has
	// completely loaded.
	boolean imageDone;

/* Menu data */
	Rectangle[] hitArea;
	Rectangle[] srcRect;
	Point[] dstPt;
	boolean[] down;
	String[] url;

/* Submenu data */
	String[][] itemUrl;
	String[][] item;

// If >= 0, this fields holds the index of the current menu.
	// If -1, no menu is current.
	int curMenu;

// If >= 0, this fields holds the index of the current menu item.
	// If -1, no menu item is current.
	int curMenuItem;

// This is an array of rectangles - one rectangle for each menu item.
	// Each rectangle specifies the
	// location (relative to the left-corner of the applet) of a menu item.
	//
	// menuItemRect is null when curMenu is -1.
	// It becomes non-null when curMenu >= 0.
	//
	// Note: it would have been better programming to define classes for
	// the menu and menu items.  However, I decided for this little applet
	// to keep the number of class files to a minimum to minimize the download
	// time.
	Rectangle[] menuItemRect;

// This is the color to paint "behind" the image.
	Color bgColor;

// [0] is the text color of a menu item; [1] is the text color of a highlighted
	// menu item.
	Color fgMenuColor[] = new Color[2];

// This is the background of a menu item; [1] is the background color of a
	// highlighted menu item.
	Color bgMenuColor[] = new Color[2];

// marginH is the number of pixels on the left and right edges of the menu.
	// marginV is the number of pixels on the top and bottom edges of the menu.
	int marginH, marginV;

// This is the font used to display the menu item labels.
	Font f;

// This is the font metrics of 'f'.
	FontMetrics fm;

public void init() {
		int[] ints;

// Grab applet parameters.
		image = getImage(getCodeBase(), getParameter("image"));
		marginH = Integer.parseInt(getParameter("marginh"));
		marginV = Integer.parseInt(getParameter("marginv"));

// Get color parameters.
		ints = parseInt(getParameter("bg-color"), " ");
		bgColor = new Color(ints[0], ints[1], ints[2]);
		ints = parseInt(getParameter("fg-menu-color"), " ");
		fgMenuColor[0] = new Color(ints[0], ints[1], ints[2]);
		ints = parseInt(getParameter("fg-hi-menu-color"), " ");
		fgMenuColor[1] = new Color(ints[0], ints[1], ints[2]);
		ints = parseInt(getParameter("bg-menu-color"), " ");
		bgMenuColor[0] = new Color(ints[0], ints[1], ints[2]);
		ints = parseInt(getParameter("bg-hi-menu-color"), " ");
		bgMenuColor[1] = new Color(ints[0], ints[1], ints[2]);

// Create back buffer for double-buffering.
		bbuf = createImage(size().width, size().height);
		bbufG = bbuf.getGraphics();

// Determine the font from the font-height.
		int fh = Integer.parseInt(getParameter("font-height"));
		int i = fh;
		while (i > 10) {
			f = new Font(getParameter("font"), Font.PLAIN, i);
			fm = getFontMetrics(f);
			if (fm.getHeight() <= fh) {
				break;
			}
			i--;
		}

// Get the menu parameters.
		for (i=0; ; i++) {
			if (getParameter("menu"+i) == null) {
				hitArea = new Rectangle[i];
				srcRect = new Rectangle[i];
				dstPt = new Point[i];
				url = new String[i];
				down = new boolean[i];
				itemUrl = new String[i][];
				item = new String[i][];

break;
			}
		}

for (i=0; i<hitArea.length; i++) {
			String[] fields = parse(getParameter("menu"+i), getParameter("separator"));

			// Get the hit area.
			ints = parseInt(fields[0], " ");
			hitArea[i] = new Rectangle(ints[0], ints[1], ints[2], ints[3]);

// Get the source image.
			ints = parseInt(fields[1], " ");
			srcRect[i] = new Rectangle(ints[0], ints[1], ints[2], ints[3]);

// Get the destination point.
			ints = parseInt(fields[2], " ");
			dstPt[i] = new Point(ints[0], ints[1]);
			down[i] = fields[3].equals("d");
			url[i] = fields[4];

item[i] = new String[(fields.length-5)/2];
			itemUrl[i] = new String[(fields.length-5)/2];
			for (int j=0; j<item [i].length; j++) {
				item[i][j] = fields[j*2+5];
				itemUrl[i][j] = fields[j*2+6];
			}
		}
	}

	// s is a string containing 'sep' separators.  This method
	// breaks up the string at the separators and returns the resulting
	// strings in an array.  The result may have zero length but is never null.
	String[] parse(String s, String sep) {
		StringTokenizer st = new StringTokenizer(s, sep);
		String result[] = new String[st.countTokens()];

for (int i=0; i<result.length; i++) {
			result[i] = st.nextToken();
		}
		return result;
	}

// This method is similar to parse() except that the strings are
	// assumed to be decimal integers.  This method coverts these integer
	// strings into integers and returns them in an array.
	// The result may have zero length but is never null.
	int[] parseInt(String s, String sep) {
		StringTokenizer st = new StringTokenizer(s, sep);
		int[] result = new int[st.countTokens()];

for (int i=0; i<result.length; i++) {
			result[i] = Integer.parseInt(st.nextToken());
		}
		return result;
	}

public void paint(Graphics g) {
		imageDone = false;
		update(g);
	}

public void update(Graphics g) {
		Graphics g2;

if (!imageDone) {
			imageDone = g.drawImage(image, 0, 0, this);
			return;
		}

		bbufG.setColor(bgColor);
		bbufG.fillRect(0, 0, size().width, size().height);
		bbufG.drawImage(image, 0, 0, this);

		if (curMenu >= 0) {
			g2 = bbuf.getGraphics();
			// Paint the overlay image
			g2.clipRect(dstPt[curMenu].x, dstPt[curMenu].y, srcRect[curMenu].width, srcRect[curMenu].height);
			g2.drawImage(image, dstPt[curMenu].x-srcRect[curMenu].x, dstPt[curMenu].y-srcRect[curMenu].y, this);
			g2.dispose();

g2 = bbuf.getGraphics();
			for (int i=0; i<menuItemRect.length; i++) {
				drawMenuItem(g2, i);
			}
			g2.dispose();
		}
		g.drawImage(bbuf, 0, 0, this);
	}

void drawMenuItem(Graphics g, int i) {
		int x, y, w, height;
		// break the menu item label into lines.
		String[] line = parse(item[curMenu][i], getParameter("newline"));

int hi = 0;
		if (i == curMenuItem) {
			hi = 1;
			getAppletContext().showStatus(itemUrl[curMenu][i]);
		}
		g.setColor(bgMenuColor[hi]);
		g.fillRect(menuItemRect[i].x, menuItemRect[i].y, menuItemRect[i].width, menuItemRect[i].height);

// set color for text and box
		g.setColor(fgMenuColor[hi]);

// draw box around menu item.
		g.drawRect(menuItemRect[i].x, menuItemRect[i].y, menuItemRect[i].width, menuItemRect[i].height);

// draw label
		g.setFont(f);
		y = menuItemRect[i].y + marginV;
		for (i=0; i<line.length; i++) {
			g.drawString(line[i], menuItemRect[i].x+menuItemRect[i].width-fm.stringWidth(line[i])-marginH, y + fm.getAscent());
			y += fm.getHeight();
		}
	}

public boolean mouseExit(Event evt, int x, int y) {
		curMenuItem = curMenu = -1;
		repaint();
		return true;
	}

public boolean mouseEnter(Event evt, int x, int y) {
		return mouseMove(evt, x, y);
	}

	public boolean mouseDown(Event evt, int x, int y) {
		try {
			String u = null;

if (curMenuItem >= 0 && itemUrl[curMenu].length > 0) {
				u = itemUrl[curMenu][curMenuItem];
			}
			else
				if (curMenu >= 0) {
					u = url[curMenu];
				}
			if (u != null) {
				URL url = new URL (getDocumentBase(), u);

if (getParameter("target") != null) {
					getAppletContext().showDocument(url, getParameter("target"));
				}
				else {
					getAppletContext().showDocument(url);
				}
			}
		}
		catch (Exception e) {
			e.printStackTrace();
		}
		return true;
	}

public boolean mouseMove(Event evt, int x, int y) {
		if (curMenu >= 0) {
			int sm = inMenu(menuItemRect, x, y);

if (curMenuItem != sm) {
				curMenuItem = sm;
				repaint();
			}
			if (sm >= 0) {
				return true;
			}
			curMenu = -1;
		}

int m = inMenu(hitArea, x, y);
		if (m != curMenu) {
			curMenu = m;

// A new menu is now active so compute menuItemRect.
			if (m >= 0) {
				// Minimum width
				int maxWidth = 50;
				int maxHeight = 0;

menuItemRect = new Rectangle[item[curMenu].length];
				for (int i=0; i<menuItemRect.length; i++) {
					String[] line = parse(item[curMenu][i], getParameter("newline"));

for (int j=0; j<line.length; j++) {
						int w = fm.stringWidth(line[j]);
						if (w > maxWidth) {
							maxWidth = w;
						}
					}

menuItemRect[i] = new Rectangle();
					menuItemRect[i].height = parse(item[curMenu][i], getParameter("newline")).length * fm.getHeight() + 2 * marginV;
					maxHeight += menuItemRect[i].height;
				}

// Add one extra pixel for the left edge.
				maxWidth +=  2 * marginH + 1;
				if (down[m]) {
					y = Math.max(0, Math.min(size().height-maxHeight-1, dstPt[curMenu].y + srcRect[curMenu].height-1));
				}
				else {
					y = Math.max(0, Math.min(size().height-maxHeight-1, dstPt[curMenu].y - maxHeight));
				}
				x = dstPt[curMenu].x + srcRect[curMenu].width-maxWidth-1;
				for (int i=0; i<item[curMenu].length; i++) {
					menuItemRect[i].x = x;
					menuItemRect[i].y = y;
					menuItemRect[i].width = maxWidth;
					y += menuItemRect[i].height;
				}
				getAppletContext().showStatus(url[curMenu]);
			}
			repaint();
		}
		return true;
	}

// Returns the index of the rectangle in rs containing x and y.
	// Returns -1 if either rs is null or x and y is not in rs.
	int inMenu(Rectangle[] rs, int x, int y) {
		if (rs != null) {
			for (int i=0; i<rs.length; i++) {
				if (rs[i].inside(x, y)) {
					return i;
				}
			}
		}
		return -1;
	}
}
